Description of transformer coil winding machine ZPX1000

Transformer coil winding machine ZPX1000 is a professional transformer making equipment for winding coils. The transformer coil winding machine can wind both copper wire and aluminium wire to make different sizes of wire coils. The transformer coil winding machine is provided with main winding motor, wire laying unit, insulation decoiler, tension adjustable pay-off unit, pneumatic system, PLC, and servo motors, etc. With wire laying unit driven by servo motor, the transformer coil winding machine can lay the wire automatically when winding. With PLC, the transformer coil winding machine can be with many automatic function. The transformer coil winding machine is provided with HMI, which make the coil winding machine be operated very easily.

Main components of transformer coil winding machine ZPX1000

1.  Main frame

2.  Winding unit

3.  Automatic wire laying unit

4.  Insulation decoiler

5.  Electronic control system

6.  Pneumatic system

Technical parameters of transformer coil winding machine ZPX1000

Typical standard specifications of transformer coil winding machine ZPX1000 are shown below and the coil winding machine can also be manufactured as requested.

Fig 1: Transformer coil winding machine ZPX1000's front view

Fig 2: Transformer coil winding machine ZPX1000's wire guide driven by sero motor
